IMC/EMT Conduit Tube
Cov khoom siv hlau feem ntau siv rau kev xaim hluav taws xob yog qhov tsim nyog rau cov cheeb tsam hnyav dua thiab tsim nyog rau kev tiv thaiv kab mob hauv qhov chaw nyob sab hauv tsev lossis qhov chaw qhuav.
Hauj lwm lawm
IMC/EMT Conduit Tube yog ob hom hlau txuas siv dav hauv cov tshuab hluav taws xob los tiv thaiv cables. Lawv tsuas yog siv los ua kom muaj kev nyab xeeb ntawm cov kab hluav taws xob thiab tiv thaiv kev puas tsuaj rau cov cables los ntawm ib puag ncig sab nraud.
IMC conduits yog tuab dua li EMT conduits, muab kev tiv thaiv lub cev muaj zog, thiab haum rau ib puag ncig uas xav tau kev tiv thaiv siab. IMC conduits feem ntau yog tuab dua li EMT conduits, uas ua rau lawv zoo dua ntawm kev cuam tshuam, siab, lossis tshuaj lom neeg corrosion. Lawv feem ntau siv nyob rau hauv factories, warehouses, los yog lwm yam hnyav ib puag ncig los tiv thaiv cables los ntawm lwm yam kev puas tsuaj. IMC conduits yog qhov nyuaj rau nruab thiab feem ntau xav tau kev sib txuas threaded. EMT conduits yog nyias thiab sib dua, thiab feem ntau yog siv nyob rau hauv cov chaw uas cov cables muaj kev tiv thaiv me ntsis, xws li ib puag ncig sab hauv tsev hauv vaj tse lossis kev lag luam. EMT conduits yog sib zog nyob rau hauv cov khoom, yooj yim rau nruab sai, thiab feem ntau txoj kev sib txuas yog crimping es tsis threading. Txawm hais tias EMT muab kev tiv thaiv tsawg dua IMC, nws txaus rau ntau daim ntawv thov, tshwj xeeb tshaj yog nyob rau hauv ib puag ncig qhuav uas tsis ua rau lub cev poob siab.
Ob leeg yog ua los ntawm steel los yog txhuas thiab yog corrosion-resistant. Lawv xaiv feem ntau yog txiav txim siab los ntawm kev thov tshwj xeeb, ib puag ncig, thiab kev yooj yim ntawm kev teeb tsa. Hauv kev xa hluav taws xob, ob qho tib si IMC thiab EMT conduits tuaj yeem tiv thaiv cov kab hluav taws xob los ntawm kev puas tsuaj, hluav taws xob cuam tshuam, lossis ib puag ncig.
|
Qauv (MM) |
EMT Hluav Taws Xob Conduit |
|
Txoj kab uas hla (NPS) |
1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 3-12", 4" |
|
Sab nraud Diameter (MM) |
17.93/23.42/29.54/38.35/44.20/55.80/73.03/88.90/101.60/114.30 hli |
|
Sab hauv Diameter (MM) |
15.8/20.93/26.64/35.05/40.89/52.50/69.37/85.24/97.38/110.08 hli |
|
Phab ntsa Thickness 1 (MM) |
1.067/1.245/1.448/1.651/1.830/2.110 hli |
|
Phab ntsa Thickness 2 (MM) |
{{0}}.85/0.95/1.10/1.30mm |
|
Ntev 1 (MM) |
10 ft, 3048 mm |
|
Ntev 2 (MM) |
9.84ft, 3000 Nws |
Cim npe nrov: Tuam Tshoj imc/emt conduit tube manufacturers, lwm tus neeg
